OVERVIEW
- Highlight your space with its refined Design
- The screen shows the working status and displays the temperature of the hot water.
- Unique coated outer cabinet: rust-resistant and fingerprint-proof.
- Optional filter systems considering the environment of users.
- Hot water safety lock.
- Hidden faucet spout
APPLICATIONS
- office building
- public transport station
- academy
- gym / Fitness
- stadium
- hospital
- school
- Nursing homes
FEATURES / BENEFITS
- Display Screen: The screen shows the working status and displays the temperature of the hot water.
- Front panel and drip tray: ABS material + powder coated. Onepiece front panel is easy to clean. Built-in drip tray with drain connecting.
- Hot water tanks and cold water tanks: are stainless steel tanks, welded with agon joints and insulated around the tank.
- Base: Polypropylene impact-resistant material / anti-injury foot base
- Front lower panel, front upper panel frame, left and right side panels: Color steel coated panel
- Hot water safety lock.
SPECIFICATIONS
Capacity: 6,000 gallons (22,710 L)
|
Model:
|
MAXXI-3TM
|
|
Dimensions (cm.):
|
43(L) x 55(W) x 132(H)
|
|
Water Tank (Litres):
|
Hot:
|
10L
|
|
|
Ambient:
|
20L
|
|
|
Cold
|
: 3L
|
|
Water Supply:
|
Municipal Water
|
|
|
Power / Hz (Heater, Compressor):
|
220V ~/ 50Hz
|
|
|
Flow Rate & Water Temperature:
|
Hot
|
: 60.5L/H (95 °C +/- 5°C)
|
|
|
|
25.5L/H (95 °C or above)
|
|
|
Cold
|
: 18L/H (10 °C +/- 5°C)
|
|
|
|
8L/H ( 5 °C -1°C)
|
|
Watt:
|
Hot
|
: 1000w
|
|
|
Cold
|
: 125w
|
